Polyurethane Pentagon Reinforced Belt Designed For Heavy Load Transmission Featuring High Strength And Low Stretch Cord Materials

Polyurethane Pentagon Reinforced Belt Designed For Heavy Load Transmission Featuring High Strength And Low Stretch Cord Materials
Polyurethane Pentagon Reinforced Belt Designed For Heavy Load Transmission Featuring High Strength And Low Stretch Cord Materials
Polyurethane Pentagon Reinforced Belt Designed For Heavy Load Transmission Featuring High Strength And Low Stretch Cord Materials Polyurethane Pentagon Reinforced Belt Designed For Heavy Load Transmission Featuring High Strength And Low Stretch Cord Materials Polyurethane Pentagon Reinforced Belt Designed For Heavy Load Transmission Featuring High Strength And Low Stretch Cord Materials Polyurethane Pentagon Reinforced Belt Designed For Heavy Load Transmission Featuring High Strength And Low Stretch Cord Materials Polyurethane Pentagon Reinforced Belt Designed For Heavy Load Transmission Featuring High Strength And Low Stretch Cord Materials

Large Image :  Polyurethane Pentagon Reinforced Belt Designed For Heavy Load Transmission Featuring High Strength And Low Stretch Cord Materials

Product Details:
Place of Origin: China
Brand Name: jiuna
Certification: iso9001:2015
Model Number: 2mm-20mm /A-B-C-D-M-Z
Payment & Shipping Terms:
Minimum Order Quantity: 10rolls
Packaging Details: cartons/pallet
Delivery Time: 7working days
Payment Terms: L/C, T/T, D/A, D/P
Supply Ability: 100000 meters/month
Contact Now

Polyurethane Pentagon Reinforced Belt Designed For Heavy Load Transmission Featuring High Strength And Low Stretch Cord Materials

Description

Reinforced Polyurethane Pentagon Belt For Transmission 90 A Hardness
Product Overview
High-performance reinforced polyurethane belting manufactured in China, available in round and V-belt configurations with various cord material options including polyester, Kevlar, and steel wire.
Key Features
  • High-strength, low-stretch construction for demanding applications
  • Ideal for longer conveyor lengths and heavier loads
  • Multiple surface options: smooth and rough textures available
  • Hardness rating: 90 Shore A
  • Minimum order quantity: 10 rolls per size
Common Applications
Cable for canning & filling lines, live roller conveyors, olive sorting machines, potato and fruit sorting machines, veneer hold-down machines, panel board paint rollers, tile/glass/ceramic conveying systems.
Reinforced Polyurethane Round Belt Specifications
Sizeφ Roll Length Hardness With Reinforced Cord MOQ Request
4mm 200 Mtr/Rolls 85 or 90A OK 10 rolls
5mm 100 Mtr/Rolls 85 or 90A OK 10 rolls
6mm 100 Mtr/Rolls 85 or 90A OK 10 rolls
7mm 100 Mtr/Rolls 85 or 90A OK 10 rolls
8mm 100 Mtr/Rolls 85 or 90A OK 10 rolls
9mm 50 Mtr/Rolls 85 or 90A OK 10 rolls
10mm 50 Mtr/Rolls 85 or 90A OK 10 rolls
12mm 30 Mtr/Rolls 85 or 90A OK 10 rolls
15mm 30 Mtr/Rolls 85 or 90A OK 10 rolls
18mm 30 Mtr/Rolls 85 or 90A OK 10 rolls
20mm 30 Mtr/Rolls 85 or 90A OK 10 rolls
Reinforced PU V-Belt Specifications
Type X(mm) Y(mm) Hardness Length -M/Roll With Reinforced Cord
A 13 8 90-Shore A 30 OK
B 17 11 90-Shore A 30 OK
C 22 14 90-Shore A 30 OK
D 32 20 90-Shore A 30 OK
M 8 5 90-Shore A 50 OK
Z 10 6 90-Shore A 50 OK
Reinforced PU Ridge Belt & Ridge-Top V-Belt
Type X(mm) Y(mm) Hardness Length -M/Roll With Reinforced Cord
A 13 16 90-Shore A 30 OK
B 17 20 90-Shore A 30 OK
C 22 27 90-Shore A 30 OK
Reinforced PU Super Grips Belt
Type X(mm) Y(mm) Z(mm) Hardness Length -M/Roll With Reinforced Cord
A 13 8 3.5 90-Shore A 30 OK
B 17 11 3.5 90-Shore A 30 OK
C 22 14 3.5 90-Shore A 30 OK
D 32 20 3.5 90-Shore A 30 OK
Polyurethane Pentagon Reinforced Belt Designed For Heavy Load Transmission Featuring High Strength And Low Stretch Cord Materials 0
